Features
- Eliminating "hot pockets" inside the enclosure
- Ensuring equal temperature in the entire enclsoure
- Reduction of cooling needs
- Blowing direction can be adjusted in 30° steps in all directions
Air flow volume (system / unimpeded) 234 m³/hr Operating Temperature Range -10...55 °C Mounting Screw Mount (M6) or DIN Rail Dimensions A x B x C (D+E) A = Height | B = Width | C = Depth
203 x 146 x 53 mm Voltage / Frequency 120-230 V UL Voltage / Frequency 120-230 V ~ 50/60 Hz Rated current 0.18 A Power consumption 15 W Noise level 51.5 dB(A) Fuse 1 A(T) Connection Terminal block Datasheet Generate PDF No Order Information
Air flow volume (system / unimpeded) 180 m³/hr Operating Temperature Range -10 - 55 °C Mounting Screw Mount (M6) or DIN Rail Dimensions A x B x C (D+E) A = Height | B = Width | C = Depth
203 x 146 x 53 mm Voltage / Frequency 24 V DC Rated current 0.20 A Power consumption 5 W Noise level 45 dB(A) Fuse 1 A (T) Connection Terminal block Datasheet Generate PDF No Order Information
