Features
- Suitable for indoor and outdoor (black models) applications
- Models with IP 55 protection available
- Tool-free mounting, easy and quick replacement of the filter media
- Pair our FDA-approved, UL-certified protection hoods with SOLIVENT PRO filter fans for cleanroom and food-grade applications
- Customised colour options upon request
Order Number 4725902001 Brand Name SOLIVENT PRO Colour RAL 7035 Approvals CE, cURus, cULus UL File Number E498756 Accessories Hose-proof protection hood FC 4000 300 FDAHose-proof protection hood FC 4000 300Thermostat 301050 Operating Temperature Range 10°C - 60°C Mounting Wall mounted Dimensions A x B x C (D+E) A = Height | B = Width | C = Depth
255.4 x 255.5 x 43 mm Weight 0.6 Kg Cut out dimensions 224 x 224 mm Datasheet Generate PDF Instructions User manual SOLIVENT PRO Order number IP rating UL Type RAL colour Flow type1) Air flow (m³/h)2) Air flow with exhaust filter (m³/h) 4725902001 54 12 / 3R RAL 7035 N/A N/A N/A 4725902003 54 12 / 3R RAL 9005 N/A N/A N/A 4725903001 55 12 / 3R RAL 7035 N/A N/A N/A 4725903003 55 12 / 3R RAL 9005 N/A N/A N/A 1) B = Blowing – from ambient into the enclosure (standard version)
S = Suction – from enclosure to ambient (on request)2) unimpeded 50/60 Hz
Taric ode 84145915
Order Number 4725902003 Brand Name SOLIVENT PRO Colour RAL 9005 UL Typ (UL 50E) 12, 3R Approvals CE, cURus, cULus UL File Number E498756 Accessories Hose-proof protection hood FC 4000 300 FDAHose-proof protection hood FC 4000 300Thermostat 301050 Operating Temperature Range -40°C - 60°C Mounting Wall mounted Dimensions A x B x C (D+E) A = Height | B = Width | C = Depth
255.4 x 255.5 x 43 mm Weight 0.6 Kg Cut out dimensions 224 x 224 mm Datasheet Generate PDF Instructions User manual SOLIVENT PRO Taric ode 84145915
